Operational instructions for digital multibus instruments
9.17.023
8 IDENTIFICATION PARAMETERS
Data Type
Range
read/write Secured DDE Proc/par
8.1 S
ERIAL NUMBER
unsigned char[20]
String
RW
Y
92
113/3
This parameter consists of a maximum 20-byte string with instrument serial number for identification.
Example: “M11202123A”
8.2 BHTM
ODEL NUMBER
unsigned char[]*
String
RW
Y
91
113/2
Bronkhorst instrument model number information string.
*For MBC-II type length = 23 bytes, for MBC3 type the length = 27 bytes
8.3 F
IRMWARE VERSION
unsigned char[6]
String
R
Y
105
113/5
Revision number of firmware. E.g. “V1.10b”
8.4 U
SERTAG
unsigned char[16]
String
RW
Y
115
113/6
User definable alias string. Maximum 16 characters allow the user to give the instrument his own tag name. It is
advised here to limit the name up to 7 characters when using E-7000 readout and control modules. These modules can
display the tag of an instrument only up to 7 characters. E.g.: “Room1s6”
8.5 C
USTOMER MODEL
unsigned char[16]
String
RW
Y
93
113/4
Digital instrument customer model information string.
This string can be used by Bronkhorst to add extra information to the model number information.
