Page 28
BRONKHORST
®
Page 28
Operational instructions for digital multibus instruments
9.17.023
6.9 A
LARM DELAY TIME
unsigned char
0…255
RW
N
182
97/7
Time in seconds alarm action will be delayed when alarm limit has been exceeded.
Also time in second’s automatic reset will be delayed when sensor signal reaches safe level again.
6.10 R
ESET ALARM ENABLE
unsigned char
0…15
RW
N
156
97/9
Available alarm reset options:
Automatic
Reset
par 114
External*
Keyboard/
micro-switch
Value
bit[3]
bit[2]
bit[1]
bit[0]
0
0
0
0
0
1
0
0
0
1
2
0
0
1
0
3
0
0
1
1
4
0
1
0
0
5
0
1
0
1
6
0
1
1
0
7
0
1
1
1
8
1
0
0
0
9
1
0
0
1
10
1
0
1
0
11
1
0
1
1
12
1
1
0
0
13
1
1
0
1
14
1
1
1
0
15
1
1
1
1
*External is not used in MBC-II and MBC3 type instruments.
6.11 S
TATUS
unsigned char
0…255
R
N
This parameter is a special byte for monitoring PROFIBUS communication. It contains 8 bits with information about certain
(alarm) events.
Bit Low (0)
High (1)
0
no error in communication with channel error in communication
1
no parameter process error
a parameter process error has occurred
2
no parameter error
a parameter error has occurred
3
no parameter type error
a parameter type error has occurred
4
no parameter value error
a parameter R value error has occurred
5
no error
a parameter process claim or command error has occurred
6
Reserved
7
Reserved
This parameter cannot be read via FlowDDE.
6.12 S
TATUS OUT POSITION
unsigned char
0…255
R
N
Index pointing to the first byte in the PROFIBUS output data for which the above status bits applies (only for PROFIBUS).
This parameter cannot be read via FlowDDE.
