SNM-1001L Satellite Modem Revision 1
Front Panel Operation MN/SNM1001L.IOM
4–74
FUNCTION SELECT: UTILITY: DEMODULATOR: RX SYMBOL RATE
RX SYMBOL RATE
64.000 Ksps
Status Only. Programmable with 4.800 to 2500 ksps. Provides the symbol rate corresponding to
the data rate, code rate(s), modulation, and overhead (framing) programmed into the demodulator.
4.3.6.4 FUNCTION SELECT: UTILITY: INTERFACE
UTILITY
INTERFACE
Select information to view using the [
←] [→] arrow keys, then press ENTER.
FUNCTION SELECT: UTILITY: INTERFACE: TX OVERHEAD TYPE
TX OVERHEAD TYPE
NONE
Note: Overhead types are selectable only when Custom is selected for modem type in the Utility:
Modem Type menu.
FUNCTION SELECT: UTILITY: INTERFACE: RX OVERHEAD TYPE
RX OVERHEAD TYPE
NONE
Note: Overhead types are selectable only when Custom is selected for modem type in the Utility:
Modem Type menu.
