LIVEMIX CS-DUO 40
MIX-16/32 UPDATE INSTRUCTIONS
The MIX-16/32 can be updated with a CS-DUO or a PC application. You can update with a CS-DUO
if:
• The MIX-16/32 serial number is greater than 12-02-01030
• The MIX-16/32 firmware is 1.01 or above
• The CS-DUO firmware is 1.31 or above
If your MIX-16/32 does not meet the criteria above, it can be updated with a Windows PC
application. In most cases, this will bring your MIX-16/32 up to date and subsequent updates can be
performed with the CS-DUO. For reference, both methods are listed below.
TO UPDATE THE FIRMWARE OF THE MIX-16/32 WITH THE PC APPLICATION:
1. Update all CS-DUO’s to the latest version per the instructions above.
2. Download the MIX-16/32 Update Application from http://www.digitalaudio.com/support.
3. Connect the USB port on the MIX-16/32 to a Windows computer.
4. Wait for the MIX-16/32 drivers to fully install.
5. Run the MIX-16/32 Update Application. A second set of drivers will be installed at the start of
this process and may take a few minutes. Once the updater has started, a progress bar will show
the progress. Do not turn off the power until the update is complete or you may damage the
unit
6. Press the Finish button.
7. Disconnect the MIX-16/32 from the PC and verify that the update was successful by checking
the firmware version with the CS-DUO.
TO UPDATE THE MIX-16/32 WITH A CS-DUO:
1. Download the latest firmware from
http://www.digitalaudio.com/support .
2. Unzip the firmware zip file and copy the LMUPDATE folder to
the root directory of a USB flash drive. Please make sure the
LMUPDATE folder is not in another folder.
3. Go to the Livemix Version Info screen by pressing Mix Tools,
then Global Setup, then Livemix Version Info.
4. Press the “Update MIX-16/32 Firmware” button.
5. On the confirmation screen, Press YES to begin the update. If
you do not want to update, press NO.
6. Insert the flash drive that contains the update when
prompted. Press CONTINUE to start or EXIT to cancel. Once
the firmware update has started, make sure you do not turn
off the power to the MIX-16/32 or you may damage the unit.
If updating with the CS-DUO does not work, please use the PC Application.
NOTE:
Some updates take a while
to complete. If updating the
MIX-16/32 from the CS-DUO,
it works best to have only the
CS-DUO you are using to update
connected to the system.
