Page 56
52 DR
®
VERSA-PRO
™
Z-MOWER
Parts List - Lower Chassis Assembly
NOTE:
Part numbers listed are available through DR Power Equipment.
Ref# Part#
Description
01 228371 Hydro
Belt
02
159220 Clutch for 1" Engine Shaft
03
202071 Pulley, Engine Drive, 1"
04
202081 Pulley, Hydro Drive
05
159620 Bushing, Hydro Pulley
06
227501 Bracket, Clutch
07
161900 Washer, Lock, Split, 1/4"
08
227781 Bolt, 1/4"-20 x 1" HCS
09
227961 Washer, Flat, 5/16"
10
227911 Nut, Nylock, 5/16"-18
11
228131 Bolt, 7/16"-20 x 3" Fine Thread
12
228021 Washer, Split, 7/16"
13
168411 Spacer, Engine Shaft, 1" ID
14
228151 Key Stock, 1/4" x 3/4"
16
228141 Key Stock, 3/16" x 1"
17
227831 Bolt, 5/16"-18 x 2" HCS
18
202061 Pulley, Idler, Deck
19
227981 Washer, Flat, 1/2"
20
176261 Spring, Mule Drive
21
167270 Bolt, Eye, 5/16"-18 x 3-1/2"
22
225261 Bushing, 1" ID, Bronze
23
226051 Fitting, Grease, 5/16", Drive
24
225421 Pin, Cotter
25 226631 Idler
Assembly
26 227931 Nut,
Nylock,
1/2"-13
