Description IPE2500A and IPE2500A-MLS Paging Encoder/Desktop Controller
03/12 10
Performance Specifications
Color ..................................................................................................................................................... Black
Physical size .................................................................................................... 7.6 W
 8.9 L  4.7 H inches
Weight ................................................................................................................................................ 2.4 lbs.
Temperature range ............................................................................................................. −35
 C to +70 C
Humidity ..................................................................................................... 95% at 50  C (non-condensing)
Line impedance ............................................................................................................... 600 ohms, nominal
Power Input ................................................... 10.5 to 16 V dc; 500 mA maximum from supplied ac adapter
Safety ..............................................................................................
Class III SELV powered equipment.
Powered by UL-listed (E104603)
and CSA-certified (LR67888) Class 2 ac adapter.
Emissions: ....................................................................... USA: FCC Part 15, Sub. B- Verification.
Canada: ICES – 003
Line Interface ................................................................................................................ FCC Part 68 Exempt
(Category II Tariff #260 service for private/leased line applications)
Canada: IC CS03-8
Nominal input level ........................................................................................................................ −10 dBm
Nominal output level ......................................................................................................................... −10 dB
Range
−14 to +12 dB into 560 ohms
Frequency response................................................................... +3 dB, 300 to 3000 Hz (except notch filter)
Hum and noise .................................................................................. Less than −45 dB below rated outputs
Audio output to speakers ................................................. 1 watt minimum with level in compression range
Audio Distortion ............................................................................................................. Less than 3% THD
Maximum number of remotes .................................................................................................................. Ten
Control functions
Guard tone ................................................................................................. 2175 Hz, programmable
F1–F16 .................................... Each is programmable from 550 to 2050 Hz in 100 Hz increments
Monitor ................................. 2050 Hz, programmable from 550 to 2050 Hz in 100 Hz increments
