LPC 48 / 96 Users Manual
Page 40
5 Submasters
5.1 Submaster Properties
The Submaster record screen is used to record channel levels, as well as all
other properties.
Page - selects the current Submaster page. The current page can also be
set at any time using the front panel Page key.
Sub - this control selects the Submaster to be recorded.
Title - a name can be set for the Submaster. This title will be shown in the
Submaster Run screen.
Upfade and Downfade - sets up and down fade time for a Submaster. Fade
times only apply to bump toggle mode.
Linked Chase - each Submaster can have a chase linked to it. Bringing up a
Submaster will then start the selected chase.
Chase Rate - sets the speed of the linked chase.
5.2 Moving about the screen
Left and right arrow keys are used to 'tab' from field to field.
Adjust the levels within a field with up and down arrows, or use the keypad to
enter a new value.
5.3 Recording Submasters
Selecting the Record and Submaster tabs bring up the Submaster Record
screen.
The screen shows Submaster properties at the top of the screen, and channel
levels at the bottom (See Figure 23).
Channel levels shown are the actual LPC output, so previously recorded
