3 | Introduction
RH2 Models
The RH2 is the most advanced residential steam humidifier available and provides steady and
reliable humidification for a home using the same proven cylinder technology as Nortec’s
industrial electrode platform. The RH2 is available in 2 models: Duct, and Space. The duct
model is designed for connection to a steam distributor installed in a supply air duct, or for
connection to a remote blower pack. The space model is designed for applications where
humidity is to be introduced directly into the conditioned environment. The two models can be
differentiated by the grille in the humidifiers front cover, see Figure 2: RH2 Models.
.
Figure 2: RH2 Models
Table 1: RH2 Specifications
Model - Part No. Volts Capacity
lb (kg)
KW Amps Phase Max Ext
Fuse
Standard
Cylinder
Net/Full
Weight
lb (kg)
RH2 Space - 2560952
110-120 4 (1.8) 1.5
1 20 202
16 / 22
(7.5 / 10.0)
208 6.9 (3.1) 2.6 12.7
220-240 8 (3.6) 3.0
RH2 Duct - 2560953
110-120 5 (2.3) 1.9
1 20 202
15 / 21
(7.0 / 9.5)
208 8.7 (4.0) 3.3 15.9
220-240 10 (4.6) 3.8
