9250 Manual Version 1.2 | Quantum Composers 7
3. Front & Back Panel Overview
Front Panel
Indicators
A total of 6 separate LED indicators are included on the front panel of the 9250 series. The
following details the type of indication they represent.

Quantum Logo Indicates the unit is powered on and system status.

Channel A-D Indicates which channels are in the enabled state.

Active Indicates the unit is armed and/or channels are
actively pulsing (or waiting to be triggered).
Run/Stop/Power Button
The Run/Stop button serves the dual purpose of both powering on/off the unit as well as
enabling/disabling the system output. It should be noted that only a short press is needed to
both turn on and arm/disarm the unit. The button needs to be pressed and held for
approximately 1 second in order to power off the unit. In the power off sequence the active
settings are saved and reloaded when the unit is power back on.
The following image represents the front panel of a 9250:
Figure 3.1 - 9250 Front Panel
