TASCAM DR-44WL

Model for EEA (European Economic
Area)

This equipment complies with the harmonised

standards of DIRECTIVE 1999/5/EC (R&TTE).

Labeling of conformity
CE marking:

CAUTION
Changes or modifications not expressly approved by

the party responsible for compliance could void the

user’s authority to operate the equipment.
CAUTION
Authorization of wireless devices are different in

countries or regions. Please use only in the country

where you purchased the product.

• Depending on the country, restrictions on the use

of Wi-Fi wireless technology might exist.

Confirm the laws and regulations of the country or

region where you want to use the unit before use.

Radiation Exposure require-

ments

This equipment meets the regulation, which is

recognized internationally, for the case of human

exposure to radio waves generated by the trans-

mitter.
Based on the following two conditions:

• End-users and installers must be provided with

antenna installation instructions and transmitter

operating conditions for satisfying RF exposure

compliance.

• This equipment should be installed and operated

with minimum distance 20 cm (8”) between the

radiator and your body.

Statement of compliance

Model for USA

This device complies with FCC radiation exposure

limits set forth for an uncontrolled environment.

Model for Canada

The device meets the exemption from the routine

evaluation limits in section 2.5 of RSS 102 and

compliance with RSS-102 RF exposure, users can

obtain Canadian information on RF exposure and

compliance.

EEA (European Economic Area) model

This equipment complies with EN.62311; Assessment

of electronic and electrical equipment related to

human exposure restrictions for electromagnetic

fields; the harmonised standard of DIRECTIVE

1999/5/EC.

Information for interference

(FCC requirements)

This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation.
This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and

used in accordance with the instructions, may cause

harmful interference to radio communications.
However, there is no guarantee that interference will

not occur in a particular installation.
If this equipment does cause harmful interference to

radio or television reception, which can be deter-

mined by turning the equipment off and on, the

user is encouraged to try to correct the interference

by one or more of the following measures.

• Reorient or relocate the equipment and/or the

receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a

circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV

technician for help.

Declaration of Conformity
Model Number :

DR-44WL

Trade Name :

TASCAM

Responsible party : TEAC AMERICA, INC.
Address :

1834 Gage Road, Montebello,

California, U.S.A.

Telephone number : 1-323-726-0303
This device complies with Part.15 of FCC Rules.
Operation is subject to the following two

conditions:
1) This device may not cause interference, and
2) This device must accept any interference,

including interference that may cause undesired

operation.

DECLARATION OF CONFORMITY

We, TEAC EUROPE GmbH.

Bahnstrasse 12, 65205 Wiesbaden-

Erbenheim, Germany declare

in own responsibility, the TEAC

product described in this manual is in compliance

with the corresponding technical standards.

Contents

IMPORTANT SAFETY INSTRUCTIONS .........................3
Wireless equipment precautions ................................3

Compliance of radio transmitter and interference

Introduction.........................................................................4
Included items ....................................................................4
Note about the Reference Manual .............................4

Radiation Exposure requirements .................................4

Information for interference

(FCC requirements) ..................................................................4

Precautions for placement and use .............................5
Beware of condensation .................................................5
Cleaning the unit ...............................................................5
Using the TEAC Global Site ............................................5
User registration ................................................................5
Names and Functions of Parts ......................................5

Top panel .......................................................................................5

Front panel ....................................................................................5

Left side panel.............................................................................5

Right side panel .........................................................................5

Bottom panel...............................................................................5

Home Screen .......................................................................6
Preparation ..........................................................................6

Preparing the power supply ..............................................6

Starting up the unit .................................................................7

Setting the built-in clock .....................................................7

Shutting down ...........................................................................7

Connecting monitoring devices and

headphones .................................................................................7

Basic menu operation procedures .............................7

Menu structure...........................................................................7

Recording .............................................................................7

Recording Screen .....................................................................7

Adjusting the input level .....................................................8

Set the low-cut filter ...............................................................8

Using the level control function .....................................8

Record ..............................................................................................8

About the recording standby state ..............................8

Recording menu structure .................................................8

Playback ................................................................................9

Playing back recordings .......................................................9

Selecting the playback file (skipping) .......................9

Adjusting the playback volume ......................................9

Introduction

Thank you very much for purchasing the TASCAM

DR-44WL Linear PCM Recorder.
Before connecting and using this unit, please take

time to read this manual thoroughly to ensure you

understand how to properly set it up and connect

it, as well as the operation of its many useful and

convenient functions. After you have finished

reading this manual, please keep it in a safe place for

future reference.

This product has a Blackfin® 16/32-bit embedded

processor made by Analog Devices, Inc. This

processor controls digital signal processing.
Inclusion of this Blackfin® processor in the product

increases its performance and reduces its power

consumption.

Included items

This product includes the following items.
Take care when opening the package to avoid

damaging the items. Keep the packing materials for

transportation in the future.
Please contact the store where you purchased this

unit if any of these items are missing or have been

damaged during transportation.

• Main unit ............................................................................... × 1
• AC adapter (GPE053B) .................................................. × 1
• microSD card with adapter (in the unit)............ × 1
• USB cable (80 cm) ........................................................... × 1
• AA alkaline batteries ...................................................... × 4
• Fur windscreen .................................................................. × 1
• Grip ........................................................................................... × 1
• Shoe mount adapter ..................................................... × 1
• Soft case ................................................................................ × 1
• Owner’s Manual (this document)

including warranty ......................................................... × 1

Note about the Reference

Manual

This Owner’s Manual explains the main functions

of this unit. Please see the Reference Manual for

information about all the unit’s functions.

Connecting with a Computer .......................................9

Exchanging files with a computer .................................9

Disconnecting the unit from a computer ................9

Settings and Information Display ...............................9

Turning the built-in speaker off .......................................9

System settings ..........................................................................9
