8. SPACER BAR ASSEMBLY KITS
PipeDIA
True OD
P/N of the
SpacerBar
Assembly
in.
mm
Model 614 RBL
7"
7.00"
177.8 mm
08-0353
7"
7.63"
193.8 mm
08-0352
8"
8.63"
219.2 mm
08-0351
10"
10.75"
273.1 mm
08-0350
12"
12.75"
323.9 mm
08-0349
Model 616 RBL
10"
10.75"
273.1 mm
08-0351
12"
12.75"
323.9 mm
08-0350
14"
14.00"
355.6 mm
08-0346
Model 620 RBL
14"
14.00"
355.6 mm
08-0348
16"
16.00"
406.4 mm
08-0347
18"
18.00"
457.2 mm
08-0346
Model 624 RBL
18"
18.00"
457.2 mm
08-0348
20"
20.00"
508.0 mm
08-0347
22"
22.00"
558.8 mm
08-0346
Model 630 RBL
24"
24.00"
609.6 mm
08-0348
26"
26.00"
660.4 mm
08-0347
28"
28.00"
711.2 mm
08-0346
Model 636 RBL
30"
30.00"
762.0 mm
08-0348
32"
32.00"
812.8 mm
08-0347
34"
34.00"
863.6 mm
08-0346
Model 642 RBL
36"
36.00"
914.4 mm
08-0348
38"
38.00"
965.2 mm
08-0347
40"
40.00"
1016.0 mm
08-0346
