1. Wrap Video Eyewear
2. Multi-connect Connector
3. Battery / Control Box
4. Stereo Earphones 5. Earphone Noise Isolators
6. Safety & Warranty Booklet
7. Composite Audio/Video Cable
8. Composite AV Cable for iPod/iPhone
Using Your Eyewear
The following steps guide you through the process of using your video eyewear to view
standard 2D & 3D video content on a device equipped with composite cable connectors or
an iPod/iPhone.
1. Open the back panel of the Battery/Control Box and insert
the batteries as indicated.
2. Plug the Multi-connect cable from your video eyewear into
the matching connector on the Battery/Control Box, as shown above.
3. Plug your stereo earphones into the jacks on either side of the display panels.
4. Connect the Composite video cable into the port labeled “AV” on the Battery/Control
Box. You may substitute the Composite Video Cable with a Composite iPod/iPhone or
other compatible cable.
1. Multi-connect cable
2. Left earphone jack
3. Left display panel
4. Focus adjustor cover
5. Adjustable nose pad
6. Right display panel
7. Right earphone jack
8. Mini-port connector
