43
Network configuration example
In a data center, a network is assigned to Tenant A and configured with the following recourses:
•
VLAN ID of 150
•
Maximum connections of 200
•
VSI Type A
•
Maintainer a
To add the network:
1.
Click the Resource tab.
2.
From the navigation tree, select VAN Connection Manager > Network.
All networks appear in the network list.
3.
Configure the following network parameters, as shown in
.
a.
Enter Network A in the Name field.
b.
Enter 150 in the VLAN ID field.
c.
Enter Assign this network to Company A in the Description field.
d.
Click the Add icon
to add VSI Type A to the right field.
e.
Select maintainer a in the maintainer group.
