66
{
Destination Interface—Enter the interface name of the edge switch the VM connects to after
the VM migration. This field supports fuzzy matching.
{
Destination Physical Server—Enter the device label of the physical server where the VM
resides after the VM migration. This field supports fuzzy matching.
{
Migration Result—Select a migration result. Options are All, Success, Failure, Partial Success,
Running, and Waiting.
{
Migration Start Time/Migration End Time—Select or enter the migration start time and end
time, in the format YYYY-MM-DD hh:mm:ss.
6. Click Query.
All migration records that match the query criteria appear in the list.
To clear the query criteria and display all migration histories, click Reset.
To hide the advanced query area, click Close.
Viewing the operation records of a VM migration process
Perform this task to view the connection deployment and undeployment processes executed by VCM
during VM migration.
To view the operation records of a VM migration process:
1. Click the Resource tab.
2. From the navigation tree, select VAN Connection Manager > Life Cycle Report.
3. On the Life Cycle Report page, click the Migration History tab.
All VM migration records appear in the migration history list.
4. Click the Operation Information icon for a record in the Operation field.
The list displays the connection deployment and undeployment processes triggered by the
migration process.
Viewing migration details
Perform this task to view detailed information about a VM migration, including the connection
deployment and undeployment processes performed to migrate the VM network configuration.
For VM migrations that are partial successful or failed, viewing migration details can find the reason.
To view migration details:
1. Click the Resource tab.
2. From the navigation tree, select VAN Connection Manager > Life Cycle Report.
3. On the Life Cycle Report page, click the Migration History tab.
All VM migration records appear in the migration history list.
4. Click the View icon for a record in the Operation field.
The Migration Details window displays the following areas and parameters:
Basic Information area
{
Migration Time—Time when VM migration ends.
{
VM—Name of the migrated VM.
