LDK 4410 + LDK 5420 3G Fiber Transmission System User’s Guide (v1.0) 13
Chapter 1 - Introduction
1.3 Main features
• The 3G Fiber Transmission System offers flexible and multiple audio and video
connectivity at the base station.
• Allows video transmission, power and control of cameras up to a distance of 4,000 m
(13,120 ft) , using hybrid Fiber cables.
• Transmission of 1080p50/59.94, 1080i50/59.94, 720p50/59.94 and many psf HD video
formats.
• Transports the following digital signals from camera to base station: main video signal,
four audio channels (including embedded digital audio), two intercom channels, control
and private data.
• Transports the following digital signals from base station to camera: power, two external
HD video channels, teleprompter signal, three intercom channels, control and private data.
• Full camera control via Grass Valley’s C2IP Ethernet-based control network. Compatible
with Grass Valley’s Fusion product line for seamless integration with other Grass Valley
broadcast products.
• Two-wire or four-wire intercom compatible with international standards.
• The adapter has a compact and ergonomic design and is dockable with all Grass Valley HD
cameras.
• All operational controls within easy reach at the back panel of the camera adapter.
• The swiveling Fiber connector on the camera adapter provides a maximum of freedom
and moveability for the operator.
• Designed to fit onto the new Grass Valley Reflex SuperXpander: the hot shoe connection
enables swift and easy coupling with the SuperXpander without the need for flying leads
or other cabling.
• Base station built in a compact 2U high 19-inch rack housing.
• Teleprompter, color bar, HD-SDI outputs standard on board.
• The digital transmission backbone and power module meet the most demanding
broadcasting needs.
• Heavy-duty design with a new base station power unit with low power consumption, ideal
for OB vans.
• Both HD and simultaneous high-quality SD outputs (optional) are available.
