LDK 4410 + LDK 5420 3G Fiber Transmission System User’s Guide (v1.0) 49
Chapter 5 - Menus
5.1.3 Monitoring menu
Menu item Values Description Level File
Monitoring source R, G, B, Y Selects signal on monitoring HDTV analog
output. Oper Scene
Menu
Display On, Time Selects the menu display to be permanently
on (visible) or to disappear after a set time. Oper Oper
Menu Time 5..99 (10) Sets the length of time the menu is
displayed when the Display mode is set to
Time. Oper Oper
Menu Level Oper, Inst, (Serv) Sets the user access level for the menu. Oper -
Service Mode Exec > Are your sure? Enters the service access level. Oper -
Status bar
Studio
Studio On, Off Displays the studio name in the status bar. Oper Oper
Name <studio name> Edit the studio name string value. Oper -
Operator
Studio On, Off Displays the operator’s name in the status
bar. Oper Oper
Name <operator name> Edit the operator’s name string value. Oper -
Camera Number On, Off Displays the camera number in the status
bar. Oper Oper
Cable Length Off, Perc, Lngth Displays the cable length in percentage
used or length left. Oper Oper
HD Out Text
Warning Y-pos 1..14 (14) Sets vertical level (in lines) for the warning
messages on the text output(s). Install -
CamName Y-pos 1..14 (1) Sets vertical level (in lines) for the camera
name on the text output(s). Install -
