LDK 4410 + LDK 5420 3G Fiber Transmission System User’s Guide (v1.0)
61
Chapter 5 - Menus
SW2
EIris, FocAst, EXT1, EXT2 Assigns a function to Switch 2:
EIris = Turns extended auto iris on or off;
FocAst = Turns focus assist on or off;
EXT1 = switch VF to external signal 1;
EXT2 = switch VF to external signal 2.
User 0
Oper
SW2 Control
Mom., Alt.
Selects behaviour of Switch 2
momentary or alternating..
User 0
Oper
VTR Start
PROD, ENG , Zoom,
EXT1, EXT2
Assigns a function to VTR Start switch:
PROD = Production intercom;
ENG = Engineering intercom;
Zoom = Viewfinder zoom function;
EXT1 = switch VF to external signal 1;
EXT2 = switch VF to external signal 2.
User 1
Oper
VTR St. Control
Mom., Alt.
Selects behaviour of VTR Start switch:
momentary or alternating.
User 1
Oper
VTR Lens
PROD, ENG , Zoom,
EXT1, EXT2
Assigns a function to VTR Lens switch:
PROD = Production intercom;
ENG = Engineering intercom;
Zoom = Viewfinder zoom function;
EXT1 = switch VF to external signal 1;
EXT2 = switch VF to external signal 2.
User 1
Oper
VTR L. Control
Mom., Alt.
Selects behaviour of VTR Lens switch:
momentary or alternating.
User 1
Oper
RET Lens
Zoom, EXT, FocAst
Assigns a function to RET Lens switch:
Zoom = Viewfinder zoom function;
EXT = switch VF to external signal (select
EXT1 or 2 with the switch at the rear of the
camera);
FocAst = Focus assist function.
User 1
Oper
RET Control
Mom, Alt.
Selects behaviour of RET Lens switch:
momentary or alternating.
User 1
Oper
RET2 Switch
Zoom, EXT
Assigns a function to RET2 Lens switch:
Zoom = Viewfinder zoom function;
EXT = switch VF to external signal (select
EXT1 or 2 with the switch at the rear of the
camera);
User 1
Oper
RET2 Control
Mom., Alt.
Selects behaviour of RET2 lens switch:
momentary or alternating..
User 1
Oper
2” VF Option
None, Disab
Selects behaviour of the Option switch on
the control panel of the 2-inch viewfinder.
User 1
Oper
Handgrip Left
PROD, ENG
Selects intercom channel to use with the
left button under the handgrip.
User 1
Oper
Fan Operation
Head Fan
Off, On
Turns the head fan on or off. Turns itself on
after 120 min. or when temperature is too
high.
User 3
-
adapter Fan
Off, On
Turns the adapter fan on or off. Turns itself
on after 120 min. or when temperature is
too high.
User 3
-
Install
Values
Description
Level
File
