56 LDK 4410 + LDK 5420 3G Fiber Transmission System User’s Guide (v1.0)
Chapter 5 - Menus
Eth MAC <MAC address> Displays the Ethernet MAC address of the
network adapter. Oper
Eth Link Type Unknown, 10Mb/Half,
10Mb/Full, 100Mb/Half,
100Mb/Full Displays the Ethernet link type for the C2IP
network. Oper
Eth Link State Connected, disconnected Displays the Ethernet link state. Oper
Audio/Intercom Board
Self test exec > run Select exec to run the diagnostic self test. Oper
ENG Test Tone Intern run > ok (error) Oper
PROD Test Tone Intern run > ok (error) Oper
PROG Test Tone Intern run > ok (error) Oper
ENG Test Tone Studio run > ok (error) Oper
PROD Test Tone Studio run > ok (error) Oper
Digital Output Board
FPGA Temp (C) <temp> Displays current FPGA temperature (C) Oper
FPGA Temp (F) <temp> Displays current FPGA temperature (F) Oper
Transmission Diag.
Transmission System HDDT, Triax, Mobox,
Fib_A, Fib_D, Unkno,
FibHS Displays the transmission system in use. Oper
CAM -> BS
Fiber Cable Status Oper
Fiber Signal Status OK, Critic, Error, NoSig Displays signal status of the fiber
connection from the camera to the
base station:
OK = Fiber transmission is OK
Critic = Signal level is critical but
transmission will continue.
Error = Signal level is too low and
transmission is not guaranteed.
NoSig = No signal detected Oper
Opt. RX Margin (dB) 0..65535 (20) Displays optic receiving margin in dB Oper
BS -> CAM
Fiber Cable Status Oper
Fiber Signal Status OK, Critic, Error, NoSig Displays signal status of the fiber
connection from the base station to the
camera:
OK = Fiber transmission is OK
Critic = Signal level is critical but
transmission will continue.
Error = Signal level is too low and
transmission is not guaranteed.
NoSig = No signal detected Oper
Opt. RX Margin (dB) 0..65535 (20) Displays optic receiving margin in dB Oper
Communications Diag.
Camera Connected Yes, No Displays whether the camera is connected. Oper
Menu item Values Description Level File
