LDK 4410 + LDK 5420 3G Fiber Transmission System User’s Guide (v1.0) 55
Chapter 5 - Menus
5.1.8 Diagnostics menu
Menu item Values Description Level File
Camera Type <camera type> Identifies camera type (e.g. LDK 8000) Oper
BS Type <Base Station type> Identifies base station type (e.g. LDK 4400) Oper
BS Package
Package Ok, NotOK Displays package status Oper
Package 12NC 5973 Displays 12NC Oper
Package version <version> Displays package version Oper
Board ID
Data Board <12nc>, <status>,<date> Displays 12nc, status and production date. Oper
Sync/Enc Board <12nc>, <status>,<date> Displays 12nc, status and production date. Oper
Digital output Board <12nc>, <status>,<date> Displays 12nc, status and production date. Oper
HQ SDTV output Board <12nc>, <status>,<date> Displays 12nc, status and production date.
(only when HQ SDTV output Board is
installed)
Oper
Fiber Transmission Board <12nc>, <status>,<date> Displays 12nc, status and production date. Oper
Optical Connect Board <12nc>, <status>,<date> Displays 12nc, status and production date. Oper
Power Detection Board <12nc>, <status>,<date> Displays 12nc, status and production date. Oper
Audio/Intercom Board <12nc>, <status>,<date> Displays 12nc, status and production date. Oper
Board Diagnostics
Power Board
Fiber Status CAMON, TSHRT, POPEN,
SOPEN, PSHRT, NOCAM,
ERROR, OVRLD, PWOFF,
UKNOW Refer to the Diagnostics section in this
user’s guide for a description of the Fiber
Status. Oper
Local Power Status Ok, NotOK Displays status of the power board. Oper
Power Overheated Yes, No Displays status of power overheating Oper
Temperature <temp> Displays power internal temperature Oper
Fan Ok, NotOK Displays status of the internal cooling fan. Oper
Fan (V) <voltage> Displays current fan voltage Oper
Sync/Encoder Board
Reference Available None, SDTV, HDTV Displays available type of reference signal Oper
Burst Lock Yes, No Oper
Sync Lock Yes, No Oper
Ext1 Input None, HDSDI, SDI Selects input type for External video input 1 Oper
Ext2 Input None, HDSDI, SDI Selects input type for External video input 2 Oper
Data Board
Firmware Status <status> Firmware status Oper
Boot Software Id <id> Boot software identification Oper
Base Station 12NC <12nc> Base station code number (‘12nc’) Oper
Software Status <status> Base station software status Oper
