26 LDK 4410 + LDK 5420 3G Fiber Transmission System User’s Guide (v1.0)
Chapter 2 - Base station
pressing the rotary/push button toggles between these two values. If a value is displayed next
to a function that is one of several possible values, then pressing the rotary/push button or the
SELECT button on the OCP places the cursor in a list menu indicating the value currently
selected. Use the rotary/push button or the SELECT button on the OCP to point to a new
value.
Press the rotary/push button or the SELECT button on the OCP to return the cursor to the
function list. If an analogue value is displayed next to a function name, then pressing the
rotary/push button or the SELECT button on the OCP places the cursor in front of the value and
the navigation control is used to change the analogue value. Press the rotary/push button or
the SELECT button on the OCP to return the cursor to the function list.
Using Recall File to undo changes
If you make changes to the settings in the menu and you decide not to keep them, use the
Recall File function to recall a standard or stored set of values for the parameters. These files
are available in the FILES menu.
User levels
The menu items are divided into two user levels. The operator level (O) is default accessible.
Menu items with user level Install (I) are only accessible if the menu level is set to Install. To
enter the Install level proceed as follows:
1. Enter the menu.
2. Navigate to the MONITORING > MENU > MENU LEVEL item.
3. Set the Menu level to Inst.
The purpose of the user levels is to restrict the set of functions which can be changed by
whoever is using the base station. In this way a the danger of the operator accidentally
changing critical functions while shooting is reduced.
☞
Note
☞
Note
When accessed from the base station, the user level is set to Install while the user level is set
to Operator when accessed from the OCP.
