70 LDK 4410 + LDK 5420 3G Fiber Transmission System User’s Guide (v1.0)
Chapter 6 - Connectors
Monitoring video outputs
Teleprompter connectors
Reference connectors
☞
Note
☞
Note
The last loop-through output in a chain must be terminated by a 75
 terminal resistor.
☞
Note
☞
Note
The maximum number of base stations that can be looped through is 6.
Connector Signal or function
CVBS+Text CVBS (analog SD) output signal with menu text and indicators inserted.
Monitoring HD-SDI Monitoring output signal with menu text and indicators inserted.
Connector Signal or function
TP-in Teleprompter input signal (analog SD)
TP-out Teleprompter looped-through (output) signal
Connector Signal
REF-in Reference input signal (HD Trilevel sync or SD Black Burst)
REF-out Reference looped-through (output) signal
