Output Server 2 Channel Configuration
Configuring a Channel to Process SCTE104 Messages
The parameters for the upmix are only visible when a 5.1 audio group is selected (e.g
DolbyE 5.1 , DolbyD 5.1 , PCM 5.1 )
Note: Clicking Reset will revert the values to the default profile, as defined
by the type of Dolby output chosen in iTX Desktop (e.g. DolbyD 2.0, DolbyE
5.1)
4 Click Upmixing Enabled. The red cross changes to a green tick.
5 In the Stereo (L/R) Channels Level field, enter the stereo input volume level in decibels.
The minimum value is -24dB and the maximum is 6dB. The default is -6dB.
Alternatively set the level to Mute .
6 In the Stereo Width field, enter a value from 0 to 31. The default is 27.
7 In the Center (C) Channel Level field, enter the center input volume level in decibels.
The minimum value is -24dB and the maximum is 6dB. The default is 1dB.
Alternatively set the level to Mute .
8 In the LFE Level field, enter the low-frequency effects input volume level in decibels.
The minimum value is -24dB and the maximum is 6dB. The default is -10dB.
Alternatively set the level to Mute .
9 In the LFE Filter field, enter a value in hertz for low-frequency effects. The default is 80
Hz for 50Hz video formats and 66.7Hz for 59Hz video formats.
10 Click the Surround Mode field.
The Select Item dialog appears.
11 Select the required surround mode. The options are:
• Speech (default)
• Standard
• Movie .
12 In the Surround (Ls/Rs) Channels Level field, enter the surround sound input volume
level in decibels. The minimum value is -24dB and the maximum is 6dB. The default is -
5dB.
Alternatively set the level to Mute .
13 In the Surround Delay (ms) field, enter the required delay in milliseconds. The default is
16.
14 Click Save to apply and store the upmixing settings.
Alternatively, wait until you have finished making changes in other areas of the
Configuration panel, then click Save.
Configuring a Channel to Process SCTE104 Messages
The video signal to the SDI video card in the playout server can contain SCTE 104 messages
(also known as digital cue tones). iTX can detect such messages and respond to them to
start the playout of a sequence that is on hold in a schedule or end a sequence iTX is
currently playing. SCTE refer to the time space provided by broadcasters to trigger these
sequences as the “avail”. Output Server 2 gives users the ability to enable and disable
individual SCTE 104 features independently, depending on their requirements.
