2
Introducing Output Server 2
Comparison Chart - Output Server 1 and Output Server 2
Comparison Chart - Output Server 1 and Output Server 2
The table below details the differences between the Output Server 1 and Output Server 2
service.
Feature Output Server 1 Output Server 2
AJA Kona 3G SDI I/O card Supported Supported from iTX v2.6
AJA Corvid 1 SDI I/O card Supported Supported
AJA Corvid 44 SDI I/O card Not supported Supported from iTX v2.6
AJA Corvid 88 SDI I/O card Not supported Supported from iTX v2.6
Dedicated SDI I/O video card
service

(I/O Device Controller)
Not available Available from iTX v2.6
Simulcast Not supported Supported from iTX v2.6
Single server dual channel Supported with dual Corvid
L/P SDI I/O Cards only * Supported from iTX v2.6
On-air update: Active Format
Description (AFD) change Not supported Supported
On-air update: Duration
change Not supported Supported
Dolby E and D per stream
configuration Not supported Supported
XG Inside: Full audio
processing (audio flows from
OS2 to XG and back to OS2) Not supported Supported
Output Server audio
configuration: Output group
definitions Optional Mandatory
Cross conversion: 50hz to
59hz standards Permitted Not permitted
Cross conversion: Same family
of standards. For example:
• 1080i50 <-> 750p50 <-> 625
• 1080i59 <-> 720p59 <-> 525
Supported Supported
SCTE104: VANC splice
commands Supported Supported
SCTE104: Multiple operations
within Multiple Operation
Messages Supported Supported
SCTE104: Segmentation
commands to identify local
and national avail inserts) Supported Supported
