66
Operation and Maintenance of an OS2 System
Deleting a Channel
The Channel Config pop-up layout appears.
5 Click the System Wide Config tab.
6 The OS2 Ignore “Reverse Field Order” field is enabled (lit green) by default.
Click OS2 Ignore “Reverse Field Order” to disable it.
7 Click Close.
8 The Channel Config pop-up layout closes.
Note: For Output Server 2, a video asset’s detected field order can be seen
in the Field Order field on the Locations tab in the Asset layout of iTX
Desktop.
Deleting a Channel
Channels can be deleted from the ITX Channel Config dialog of TXPlay 2 Config.
IMPORTANT
• You must make sure you stop the instances of TXPlay 2 and Output Server
2 associated with the channel to be deleted before you begin.
• Deleting a channel from an playout server does not remove it from any
views in iTX Desktop.
To delete a channel:
1 On the Windows desktop of the playout server, double-click on the TXPlay 2 Config
icon. The ITX Channel Config dialog appears.
2 If there is more than one channel configured on the playout server, select the channel
to be deleted from the Channel Name drop-down list.
3 Click Delete Channel.
The channel disappears from TXPlay 2 Config.
4 Click Save to confirm the deletion.
