Chapter 1 Introduction
1-12 Profile Video File Server Installation
Table 1-5. PDR324 Factory Standard Configurations with Installable Options
Slot PDR324A PDR324D
J1 System CPU System CPU
J2 Parallel Port Parallel Port
J3
J4 System SCSI System SCSI
J5 Audio I/O
Digital AES/EBU
Audio I/O
Digital AES/EBU
J6 Video Mixer
or
Video Out
Picture Monitor (Analog)
Video Mixer
or
Video Out
Picture Monitor (Analog)
J7 Audio I/O
Digital AES/EBU
or
Video Out
Picture Monitor (Analog)
Audio I/O
Digital AES/EBU
or
Video Out
Picture Monitor (Analog)
J8 MPEG Video
Encoder/Decoder
MPEG Video
Encoder/Decoder
J9 Fibre Channel Fibre Channel
J10 Disk Recorder Master Disk Recorder Master
J11 Disk Recorder Slave Disk Recorder Slave
J12 MPEG Video
Encoder/Decoder
MPEG Video
Encoder/Decoder
J13 Video I/O
Serial Digital Component
J14 Video I/O
Analog Composite
Video I/O
Serial Digital Component
J15 Video I/O
Analog Composite
Video I/O
Serial Digital Component
J16 Reference / Timecode Reference / Timecode
J17 Remote I/O
RS422
Remote I/O
RS422
