Chapter 2 Mechanical Installation
2-2
Profile Video File Server Installation
Mounting the Slide Tracks in the Rack
Figure 2-1 shows the components of a right-hand rack slide set. Note that the chassis
sections are already attached to the Profile Video File Server and PAC208/216. When
mounting rack slides in the equipment rack, bear the following in mind:
• The Profile Video File Server occupies 5 rack units (RUs).
• The PAC208/216 occupies 2 RUs
Figure 2-1. Rack Slide Set for Right Side of Profile Chassis and Rack
Profile Chassis Section
Automatic
Rack
Section
10-32 PHS
10-32 PHS
Flat
Nut
Flat Nut Bar
Intermediate
Stop Latch
Rear
NOTE: Right-hand and left-hand stationary section is designated by the
RH and the LH marked on the rails. Stop latch holes should be towards
Stationary
