Page 85: Appendix a
Profile Video File Server Installation
A-1
Appendix
A
Specifications
General Information
This appendix provides tables of electrical specifications for the video and audio
characteristics, as well as environmental criteria and power and mechanical
characteristics. The tables in this appendix make it easier to present the specifications
in numerical values. The following terms apply to the Profile Video File Server
Characteristics and Descriptions in the tables.
Specification:
A document or a section of a document that lists and describes characteristics
and performance requirements of equipment and certain program material.
Requirement (Performance Requirement):
A statement that defines a characteristic,
usually in limit form.
Supplemental Data:
Statements that explain performance requirements or provide
performance information. These are not considered to be statements of guaranteed
performance and are not ordinarily supported by a performance check procedure.
Test Equipment
Grass Valley Group uses the following test equipment to verify the performance
requirements listed in this chapter.
• VM700A
• Signal Source (Video and Audio)
• Signal Generator
• Monitor
