Tool table: Tool data required for automatic tool measurement
For a description of the cycles governing automatic tool
measurement, see the Touch Probe Cycles Manual,
Chapter 4.
Abbr. Inputs Dialog
CUT Number of teeth (20 teeth maximum) Number of teeth?
LTOL Permissible deviation from tool length L for wear detection. If the
entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm Wear tolerance: length?
RTOL Permissible deviation from tool radius R for wear detection. If the
entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm Wear tolerance: radius?
DIRECT. Cutting direction of the tool for measuring the tool during rotation Cutting direction (M3 = –)?
R-OFFS For tool length measurement: Tool offset between stylus center
and tool center. Preset: No value entered (offset = tool radius) Tool offset: radius?
L-OFFS Tool radius measurement: Tool offset, in addition to the
offsetToolAxis parameter, between upper surface of stylus and
lower surface of tool. Default: 0 Tool offset: length?
LBREAK Permissible deviation from tool length L for breakage detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm Breakage tolerance: length?
RBREAK Permissible deviation from tool radius R for breakage detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm Breakage tolerance: radius?
