HEIDENHAIN TNC 620 523
Table of Miscellaneous Functions
M Effect Effective at block... Start End Page
M00 Stop program/Spindle STOP/Coolant OFF „ Page 198
M01 Optional program STOP „ Page 475
M02 STOP program run/Spindle STOP/Coolant OFF/CLEAR status display
(depending on machine parameter)/Go to block 1 „ Page 198
M03
M04
M05 Spindle ON clockwise
Spindle ON counterclockwise
Spindle STOP „
„
„
Page 198
M06 Tool change/STOP program run (machine-dependent function)/Spindle STOP „ Page 198
M08
M09 Coolant ON
Coolant OFF „
„
Page 198
M13
M14 Spindle ON clockwise/Coolant ON
Spindle ON counterclockwise/Coolant ON „
„
Page 198
M30 Same function as M02 „ Page 198
M89 Vacant miscellaneous function or
Cycle call, modally effective (machine-dependent function) „
„
Page 221
M91 Within the positioning block: Coordinates are referenced to machine datum „ Page 199
M92 Within the positioning block: Coordinates are referenced to position defined by
machine tool builder, such as tool change position „ Page 199
M94 Reduce the rotary axis display to a value below 360° „ Page 214
M97 Machine small contour steps „ Page 202
M98 Machine open contours completely „ Page 204
M99 Blockwise cycle call „ Page 221
M109
M110
M111
Constant contouring speed at tool cutting edge
(increase and decrease feed rate)
Constant contouring speed at tool cutting edge
(feed rate decrease only)
Cancel M109/M110 „
„
„
Page 205
M116
M117 Feed rate for rotary tables in mm/minn
Cancel M116 „
„
Page 212
M118 Superimpose handwheel positioning during program run „ Page 208
M120 Pre-calculate radius-compensated contour (LOOK AHEAD) „ Page 206
M126
M127 Shortest-path traverse of rotary axes
Cancel M126 „
„
Page 213
