8.3 Cycles for Milling Pockets,
Studs and Slots
Overview
Cycle Soft key Page
4 POCKET MILLING (rectangular)
Roughing cycle without automatic pre-
positioning 272
212 POCKET FINISHING (rectangular)
Finishing cycle with automatic pre-
positioning, 2nd set-up clearance 274
213 POCKET FINISHING (rectangular)
Finishing cycle with automatic pre-
positioning, 2nd set-up clearance 276
5 CIRCULAR POCKET
Roughing cycle without automatic pre-
positioning 278
214 CIRCULAR POCKET FINISHING
Finishing cycle with automatic pre-
positioning, 2nd set-up clearance 280
215 CIRCULAR STUD FINISHING
Finishing cycle with automatic pre-
positioning, 2nd set-up clearance 282
210 SLOT RECIP. PLNG
Roughing/finishing cycle with automatic
pre-positioning, with reciprocating
plunge infeed 284
211 CIRCULAR SLOT
Roughing/finishing cycle with automatic
pre-positioning, with reciprocating
plunge infeed 287
