Printer information display, Panel operation display – Oki ColorPainter E-64s User Manual

Page 19

Advertising

CP_Manager Instruction manual

3-3

Description

Printer Status

Online indicator

On: Online, Off: Offline

Flashing (fast): Receiving data, Flashing (slowly): In pause

Ink indicator

On: Normal, Flashing: Ink warning, Off: Ink error

Heater indicator

On: All media heaters reached the set temperatures, Flashing: Media heaters currently heating

Off: All media heaters are turned off

Error indicator

Off: No error, Flashing: Warning, On: Error

Printer panel display

Displays the printer panel.

*This can be used as a virtual panel if the area is switched to panel operation display.

Enlarge Printer Panel button

Button used to enlarge the printer panel.

Display switch buttons

Buttons used to switch between the printer information display and the panel operation display.

Display: Printer information display

Panel: Panel operation display

Print Remaining Media

Button used to print the remaining amount of the currently installed media.

Amount button

Media information

Displays information about the currently used media

Preset number: Media name Remaining length

Printable area width

Origin setting

When the media width detection mode is set to AUTO: Media width

When the media width detection mode is set to MANUAL: Manual: Media width

Heater status

Upper: Set temperature

Lower: Current temperature (the “+” mark indicates the heater is currently heating)

All heaters ON indicator

Indicates that all heaters are on when displayed.

Ambient temperature

Ink information

During cleaning, a mark (

) indicating that the ink is currently used is displayed above the corresponding ink color.

Amount remaining for each ink color (%)

Waste ink bottle information

Indicates the waste ink bottle status (5 levels)

Multiple printers connection

Button used to launch an additional instance of CP_Manager when more than one printer is connected.

button

*Displayed only when multiple printers are connected.

Description

Panel operation buttons

Same buttons as on the printer panel
