 Load
Press Load to open the store and recall interface. At this point, you can
select and read the flatness calibration list file stored. For detailed
operations, refer to the introduction in “Store and Recall”.
You can edit or modify the calibration list recalled.
 Store
Press Store to open the store and recall interface. At this point, you can
save the flatness calibration list file currently edited. For the detailed
operations, please refer to the introduction in “Store and Recall”.
Tips
Edit flatness calibration list:
1) Use the direction keys or knob to select the frequency and amplitude of
the point to be set in the calibration list;
2) Press the numeric keyboard to input the value and select the desired unit
from the pop-up unit menu or unit keys. You can also press Enter to
select the default unit Hz or dB.
3. Calibrate the flatness calibration list
When a USB power meter is connected to DSG3000 and the power meter
controller (option) is activated, the menu is lit under LEVEL  Flatness 
Calibration. You can use the power meter to measure the data in the flatness
calibration list.
 Set the state of measuring flatness list
Press Switch to select “On” or “Off”.
—
On: enable the measuring flatness list function with power meter.
— Off: disable the measuring flatness list function with power meter.
 Dwell time
Press Dwell time to set the duration of each point when sweeping the
flatness list.
Amplitude Unit
Set the unit of the RF output amplitude.
Press LEVEL and use the page up/down key
to open the 2/2 menu page; then,
press Level Unit and select the desired unit from the pop-up unit menu. The output
amplitude units available are dBm, dBmV, dBuV, Volts and Watts. Wherein, dBm,
dBmV and dBuV are logarithmic units. Volts and Watts are linear units. The default is
dBm.
