– 14 –
(5) Appliances without any indication as to power consumption
Some appliances have no indication as to power consumption; but instead the work load (output) is
indicated. In such a case, power consumption is to be worked out according to the numerical formula
mentioned below.
Efficiencies of some electrical appliances are as follows :
Single-phase motor . . . . . .0.6 to 0.75 (The smaller the motor, the lower the efficiency)
Fluorescent lamp . . . . . . . .0.7 to 0.8
Example 1: A 40W fluorescent lamp means that its luminous output is 40W. Its efficiency is 0.7 and
accordingly, power consumption will be 40
0.7= 57W. As explained in
Item (2), multiply this
power consumption value of 57W by 1.2 to 2 and you will get the figure of the necessary
capacity of a generator. In other words, a generator with a rated output of 1000W capacity
can light nine to fourteen 40W fluorescent lamps.
Example 2: Generally speaking, a 400W motor means that its work load is 400W. Efficiency of this motor
is 0.7 and power consumption will be 400
0.7= 570W. When this motor is used for a
motor-driven tool, the capacity of the generator should be multipled by 1.2 to 3 and 570W as
explained in the
ltem (3). 570 (W) x 1.2 to 3 = 684 (W) to 1710 (W)
(Output of electrical appliance)
(Efficiency)
= (Power consumption)
Applications
Incandescent lamp, Heater, etc
Fluorescent lamp, Electric tool, etc
Mercury lamp, etc
Pump, Compressor, etc
Applicable Wattage (approx. W)
RGX2900
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
RGX3600
RGX4800
800
950
1300
1500
1800
2100
3500
4100
550
650
900
1100
1200
1500
2400
2900
500
550
800
900
1100
1200
2000
2400
