– 33 –
5-2-14 Front Cover
Remove bolts and washers and take out front cover.
Fastener : M8 - 20 mm Bolt & washers (4 pcs)
Tool : Box-end wrench (12 mm)
c. Apply a few turns of seal tape around the tip of the bolt.
d. Screw the bolt into the thread of the rotor shaft.
e. Torque up the bolt by using socket wrench until rotor
comes off loose.
NOTE: The hydraulic pressure inside the rotor shaft takes
apart the rotor from the engine PTO shaft.
f. Wipe off engine oil thoroughly from rotor, rotor shaft,
engine PTO shaft and front cover.
Seal tape
(2) Use engine oil and the bolt with seal tape as a tool for
pulling out rotor as follows;
a. Pour engine oil into the center (through bolt) hole of rotor
shaft.
b. prepare a bolt with the following thread size;
RGX2900
RGX3600
RGX4800 M12 1.5
Model
M10 1.5
Bolt
