DIODE RECTIFIER
SURGE ABSORBER
The diode rectifier and surge absorber are located as
shown in the following illustrations.
DIODERECTIFIER
RGX4800
RGX2900/3600
(3) SURGE ABSORBER
Measure the surge absorber resistance.
Resistance (Ω)
