– 24 –
(9) FLOAT TYPE OIL SENSOR
Check the oil sensor when it is installed on the engine.
Check that sufficient engine oil is filled in the crankcase.
Check that there is continuity between the lead wire of
oil sensor and the ground (engine crankcase) when the
oil level is above the minimum level mark of oil gauge.
Check that there is no continuity as above when the oil
level is below the minimum level mark of oil gauge.
Oil sensor
(8) AC RECEPTACLES
Make sure that no live part wire or plastic part is burnt out.
(6) CONDENSER
Use "Dr. ROBIN" in capacitance mode to check the
capacity of condenser.
NOTE: Be sure to discharge by shorting condenser leads
each other before checking the capacitance, or the
accurate reading cannot be obtained.
If such instrument is unavailable, the condenser can be
checked by replacing with new one.
If the generator performs good with new condenser, the
cause of trouble is defect in original condenser.
MODEL
RGX2900
24
RGX3600
37
RGX4800
20 and 30
CAPACITY(
μF)
