Audio output
Channel section
1.
TRIM knob
Adjusts the volume for the channel input sound.
2.
Channel level indicator
Displays the volume level before the sound passes through the channel fader.
3.
EQ/ISO (HI, MID, LOW) knobs
Adjusts the volume of each frequency band.
Each knob adjusts in the following range.
— [HI]:
-∞ dB to +6 dB (ISO)/-26 dB to +6 dB (EQ)
— [MID]:
-∞ dB to +6 dB (ISO)/-26 dB to +6 dB (EQ)
— [LOW]:
-∞ dB to +6 dB (ISO)/-26 dB to +6 dB (EQ)
4.
COLOR knob
5.
CUE button
6.
Channel fader
Adjusts the volume for the channel output sound according to the channel fader curve set
with [
Channel Fader Curve
] in the Utility settings or on the [
SHORTCUT
] screen (pages
125, 135). Moving it up increases the volume, and down decreases the volume.
7.
Crossfader
Adjusts the volume balance between the channel output sounds specified with
[
CROSSFADER ASSIGN (A, THRU, B)
] according to the crossfader curve specified with
[
Crossfader Curve
] in the Utility settings or on the [
SHORTCUT
] screen (pages 125,
8.
—
Input selector: Selects the input source for [
CH 3
] or [
CH 4
] from devices
connected to the unit.
–
[DECK 3], [DECK 4]
: Selects a deck on the unit.
–
[LINE]
: Selects a multi player, etc. connected to the [
LINE/PHONO
] terminals.
–
[PHONO]
: Selects a turntable connected to the [
LINE/PHONO
] terminals.
–
[Bluetooth]
: Selects a PC/Mac or mobile device connected via Bluetooth.
—
[CROSSFADER ASSIGN (A, THRU, B)]
selector: Assigns the channel output
sound to the crossfader in [
CROSSFADER ASSIGN
].
–
[A]
: Assigns to the [
A
] (left) side.
– [THRU]
: Bypasses the crossfader (it doesn’t pass through the crossfader).
– [B]
: Assigns to the [
B
] (right) side.
