HP Color LaserJet Pro M454dw - Manual (Page 33)

2
NOTE: When loaded with legal-size paper, Tray 2 extends from the front of the printer approximately (2
in)51 mm.
4. Load the paper into the tray.
For information about how to orient the paper, see Tray 2 paper orientation on page 24 .
5. Make sure that the paper stack is flat at all four corners. Slide the paper length and width guides so that
they are against the stack of paper.
NOTE: To prevent jams, do not overfill the tray. Be sure that the top of the stack is below the tray full
indicator.
ENWW Load paper to Tray 2 23
