Please understand that PAXTON Automotive is constantly improving the per-
formance and look of the NOVI 2000 supercharger. Parts in your kit may
appear differently than what is pictured in this manual. This is due to pho-
tographs taken in pre-production, a change in material, or an improvement in
performance.
Rest assured that you have purchased to best quality kit that PAXTON
Automotive manufactures at this time. The installation of the materials will
remain the same.
List of Appendices
Appendix Number......DWG Number.....Rev...........DWG Title
A
1201210
G
KIT, 1993-01 DODGE RAM V10
B
1019520
C
ASY, S/C NOVI 2000 REAR DISCHARGE
C
1019602
E
ASY, S/C MOUNTING BRACKET
D
1019701
C
ASY, CRANK PULLEY
E
1019810
C
ASY, AIR INTAKE
F
1019603
D
ASY, SPRING LOADED TENSIONER
G
1015512
NC
ASY, COMPRESSOR BYPASS VALVE
H
1019910
E
ASY, AIR DISCHARGE, FUEL ENRICHMENT
I
1020101
G
ASY, AUXILIARY FUEL SYSTEM
J
1016031
B
ASY, FUEL ENRICHMENT
K
1019313
E
ASY, S/C OIL SUPPLY HOSE
L
1019314
D
ASY, S/C OIL RETURN HOSE
M
1020350
B
ASY, HEATER HOSE RELOCATION
N
1020360
B
ASY, RADIATOR HOSE EXTENSION
O
1020450
B
ASY, CRUISE CONTROL RELOCATION
P
1020550
C
ASY, WASHER BOTTLE RELOCATION
