Fig 2-h
Fig 2-i
Fig 2-j
Fig 2-k
B. Disconnect the upper radiator hose and
fold it back out of the way.
C. Unclip the window washer bottle from
the shroud. Lift the bottle and discon-
nect the two plugs and the hose from the
bottle. Set it aside. (See Fig. 2-h.)
D. With a 36mm wrench or large crescent
wrench, loosen the fan and remove it
from the water pump. Set it into the fan
shroud.
*** NOTE ***
This nut has right hand threads. (See Fig. 2-i.)
E. Remove the four screws securing the
shroud to the radiator using a 10mm
socket. Lift the shroud and fan out of the
engine compartment together. (See Fig.
2-j.).
2.4 POWER STEERING BRACKET:
A. Use a 16mm wrench, turn the belt ten-
sioner counter clockwise and remove the
stock accessory drive belt. (See Fig.
2-k.)
