2-2
P/N: 4800019
©2003 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
25SEP03 v2.0 Dodge V-10(4800019v2.0)
Fig 2-d
Fig 2-e
Fig 2-f
Fig 2-g
C. Unclip the air cleaner assembly from its
base and remove it along with the air fil-
ter element. (See Fig. 2-f.)
B. There are two bolts securing the air horn
to the core support. From the front of
the core support, use a 10mm socket and
remove the horn from the core support.
You will have to bend the bracket in
order to remove it. (See Fig. 2-e.)
2.2 AIR INTAKE ASSEMBLY:
A. Disconnect the plastic duct from
between the air cleaner assembly and
the air horn on the radiator core support
(See Fig. 2-d.).
D. Use a 7/16” deep socket and remove
the four nuts securing the air cleaner
base to the throttle body.
E. Pull the base away from the throttle
body and disconnect the crankcase vent
hose from it. Set it aside, it will not be
reused. (See Fig. 2-g.)
2.3 FAN AND FAN SHROUD:
***WARNING***
Clean up any anti-freeze spillage immediately.
Animals like the taste of coolant, and if ingested
they can become very sick, and even die.
A. With a pair of pliers, remove the lower
radiator hose and drain the coolant from
the vehicle. Replace the hose and re-
secure with the factory clamp.
