Ethernet Printer Technical Manual November 10, 2010
7
This command is for configuring the Ethernet card.
<ESC>KJR
*
Ethernet card version.
*Syntax: <ESC>KJRm,nn
*Example: <ESC>KJR5,21; Ethernet card version is 5,21.
After upgrading the firmware, the Ethernet card will send this command to the printer. Use the
printer self test to get the Ethernet card version.
<ESC>KJS
Start Page
<ESC>KJT
End Page
<ESC>KJU
*
Ethernet SNMP function
*Syntax: <ESC>KJUmn
m=0, disable the Ethernet SNMP function (default)
m=1, enable the Ethernet SNMP function
n= 1~9 seconds;
which the SNMP enquire for the
printer status. (default value:1)
If n=0x0D, this indicates n=1 second. In other words, if n is not
defined, n=1 second.
This command is for printer configuration.
<ESC>KJV
Printer aging test
<ESC>KJW
*
Enquire emulation function
*Syntax: <ESC>KJWmnop
m= total emulation items; m=3~9(0x33~0x39)
Maybe the printer will have more emulation in the future.
n= PPLA emulation; n=0(0x30), PPLA emulation does not exist.
.
n=1(0x31), PPLA emulation is used.
o= PPLB emulation; o=0(0x30), PPLB emulation does not exist.
o=1(0x31), PPLB emulation is used.
p= PPLZ emulation; p=0(0x30), PPLZ emulation does not exist.
.
p=1(0x31), PPLZ emulation is used.
If the user sends <esc>KJW to enquire emulation through Ethernet card, the printer returns
<esc>KJW3011; This represents that the printer supports 3 emulations but only PPLB and
PPLZ are used in the printer now.
<ESC>KJX
Allow the printer LEDs to blink after one of the following conditions:
1. Ethernet card upgrading process is complete.
2. IP address, subnet mask and gateway configuration settings are complete.
<ESC>KJYA
*
IP Address setting
(Data transfer from the printer to the Ethernet card )
*Syntax: <ESC>KJYAa,a,a,a,b,b,b,b,c,c,c,c
*Parameter: “a,a,a,a,”: IP address
