22
• Winding the bobbin
Pull the handwheel out to the right.
Draw the thread from spool.
Guide the thread around the bobbin winder
thread guide.
Insert the thread through the hole in the
bobbin from the inside to the outside.
Put the bobbin on the bobbin winder spindle.
Push bobbin winder spindle to the right.
With the free end of the thread held in your
hand, depress the foot control.
Stop the machine when it has made a few
turns, and cut the thread close to the hole in
the bobbin.
Depress the foot control again.
When the bobbin is fully wound, stop the
machine.
Return the bobbin winder spindle to its original
position by moving the spindle to the left, and
cut the thread.
Push the handwheel in to the left
(original position).
1
1
6
2
3
5
7
6
2
3
4
5
7
4
