GAI-TRONICS
VoIP Telephone Configuration Guide
Page 36 of 88
5.12 Current
status
The Current status page shows the status of any existing call (including "OnHook" if
appropriate), the 4 inputs, 2 outputs and the registration status of the 4 proxies as configured
on the SIP sub pages. There are no changeable parameters on this page.
Note that the input status reflects the settings on the Logic page (section 5.17). If the input is
set to detect "NONE", the status will report as Disabled. If the input is set to detect either ON
or OFF (or both), the status will report as follows:
External contact
SENSE NORMAL
SENSE INVERT
3XE
D
