GAI-TRONICS
VoIP Telephone Configuration Guide
Page 63 of 88
Section Item
Identifier
Value(s) Comments
[OUTPUT1 | OUTPUT2]
CADENCE
ON:OFF
This command sets the cadence for a contact output.
To be on for ON/10 seconds where ON is in tenths of
seconds, and then OFF for OFF/10 seconds. The
default value for ON is 10, and OFF is 0 implying the
contact does not “flash
MULTICAST
TIMEOUT [1-120]
sets an enforced delay (in seconds) between one
Multicast session ending and another beginning.
Range 1-120. Default 120
SPEAKERVOLUME 1-10
sets the speaker volume during a multicast. Volume
will revert to the setting on the AUDIO page when the
multicast session has ended. Range is 1 to 10,
default value 3.
OVERRIDE
0-8
Priority level. See section 5.18.
ADDRESS
[1-8]
xxx.xxx.xxx.xxx:ppp
p
Multicast address, must include multicast port.
FILTER
xxx.xxx.xxx.xxx:xxx
.xxx.xxx.xxx
Sets a range of acceptable multicast source IP
addresses. The phone will only accept a multicast if
the source is within this IP address range. The format
is 2 IP addresses separated by a colon. The default
is 0.0.0.0:255.255.255.255
PRIORITY
[0-8]
Priority level. See section 5.18.
OUTPUT1
[ENABLED |
DISABLED]
sets if OUTPUT1 is ENABLED or DISABLED during
this multicast
OUTPUT2
sets if OUTPUT2 is ENABLED or DISABLED during
this multicast
TONE
sets if tone 10 (TONES page) is ENABLED or
DISABLED during this multicast.
SIP
LOCALPORT XXXX
Configures the port number used for the local SIP
signalling socket to be XXXX. The default value is
5060.
PROXYFAILOVERSTAT
USES
XXX, XXX …
Contains a list of SIP status codes that will trigger a
fail over from one proxy to the next.
DONTSTARTMEDIAAT
RING
[ON | OFF]
Delay the sending of media packets to end points
until the call has been answered.
SENDDTMFLAST
[ON | OFF]
Reorder the codec sequence to end points, so that
the DTMF codec is sent last.
RTPTOS XX
This command sets the value of the TOS/Diffserv
field in the UDP packets carrying RTP data. (Default
value = 46)
SINGLEPTIME [0-63]
Forces a single packet time to the value set in ms.
See 5.4.
SENDMULTIPARTMIME
[ON | OFF]
This option is for future enhancement and should
always be set to ‘OFF’. Default value OFF.
NEWBRANCHONAUTH
BYE
[ON | OFF]
This is a legacy option that is no longer used, and
must always be set to 'ON'. Default value 'ON'.
MODE
[SERIAL | MULTIPLE]
Sets whether multiple proxies and registrars are used
serially or concurrently.
REGTIMEOUT xxxx
This command sets the Registration timeout value
that will be suggested by the telephone to a Registrar
to be xxxx seconds .The default value is 3600
seconds. Valid values are 0 to
2
32
-1
REREGTIMEOUT
Sets a period in seconds after which the phone will
force a re-registration period and the server cannot
override it.
LOCALID
[1-4]
“identity”
Sets the identity of the user/phone that will be used in
the registration process with a registrar. The Identity
parameter can consist of any alpha numeric string,
and will be used within the To:, From: and Contact:
headers.
EXAMPLE LOCALID= john.smith
would give:
To: <sip: john.smith @ gai-tronics.co.uk >
DOMAIN
FQDN minus host name
Sets the domain name to be a FQDN without the
leading host part.
Example DOMAIN= gai-tronics.co.uk
PROXY
xxx.xxx.xxx.xxx
or FQDN
Sets the IP address or the FQDN of the SIP proxy
server to be used for incoming/outgoing calls.
PROXYPORT XXXX
The port number on the proxy used for SIP protocol
signalling can be changed to XXXX using this
command. The default value is 5060
PRIORITY
[1 – 4]
Sets the failover sequence between the 4 proxies
