GAI-TRONICS
VoIP Telephone Configuration Guide
Page 62 of 88
Section Item
Identifier
Value(s) Comments
DETECT ON+OFF
This command enables the generation of messages
for both assertion and de-assertion of the auxiliary
input.
SENSE [NORMAL| INVERT]
This command inverts the sense of the auxiliary input.
If set to NORMAL a logic 0 on the input is regarded
as being the OFF state. If Set to INVERT, a Logic 1
on the input is regarded as being in the OFF state.
Default is NORMAL
SYSLOG ON
This command enables SYSLOG reporting for the
selected auxiliary input number.
SYSLOG OFF
This command disables SYSLOG reporting for the
selected auxiliary input number.
MAIL ON
This command enables email reporting for the
selected auxiliary input.
MAIL OFF
This command enables email reporting for the
selected auxiliary input
[ INPUT1 | INPUT2 |
INPUT 3 |
INPUT 4 ] MSG
“text”
This command replaces the default text message
Aux_in
ǻ<input_number> with the text entered as
the value after the = text.
The text is delimited by quote marks and is a
maximum of 40 characters. The status <on/off> is
appended to the end of the text. If “text” is blank , the
message defaults back to the Aux_IN
[ OUTPUT1 | OUTPUT2
]
GENERAT
E
(Items
marked "+"
can be
combined in
any order
separated
by a "+"
symbol
OFF
This command sets the function of output 1 or 2 to be
off. (Default State)
MUTE+
This command sets the function of output 1 or 2 to
indicate if the audio input is muted.
PULSE+
This command will cause the output to operate for the
period defined by the TIMER command, When an
activation message is received from a remote unit
RING+
This command sets the function of output 1 or 2 to be
enabled when an incoming call is present and ringing.
CALL+
This command sets the function of Volt Free Contact
1 or 2 to be enabled when an outgoing call is present
with an on /off period which is as defined by the
LOGIC SET CADENCE commands
CONNECT+
This command set the function of the output 1 OR 2
to be enabled when a call is connected.
HOOK+
This command sets the function of output 1 OR 2 to
show the status of the hook switch or
ON/OFF/TOGGLE button states. When the unit is
OFF_HOOK or ON the LED will be enabled. When
the unit is ON_HOOK or OFF the output will be
disabled
INUSE+
This command sets the function of output 1 or 2 to be
enabled when an incoming call arrives or when the
user goes off hook for an outgoing call, and disabled
when the call ends.
RINGCADEN
CE+
Causes the output to pulse in time with the incoming
ring signal cadence. This cadence is set by the
parameters for Tone 7 (TONES page).
PAGE +
Sets the output to pulse when a call is present that
has been signalled as a PAGEMODE call (see UNIT
page, section 5.5) The pulsing on /off periods are set
by the CADENCE field.
REGISTERED
+
Sets the output to pulse when the phone is registered
with at least one SIP server. Can be used as a
“phone available” indicator. The pulsing on /off
periods are set by the CADENCE field.
EMERGENCY
+
Sets the output to pulse whenever there is an
outgoing call present that has been initiated by an
EMERGENCY button. The pulsing on /off periods are
set by the CADENCE field.
ON
This command sets the function of output 1 or 2
outputs to be enabled when an incoming call arrives
or when the user goes off hook for an outgoing call,
and disabled when the call ends.
[OUTPUT1 | OUTPUT2]
TIMER
XX
This command sets the value of the timer used by the
PULSE action when the appropriate command is
received from a remote station
