T10114 Jan 2001
Sheet Feeder Model 49 Operator Manual 3-7
Switch on the power. Select ”Mode” and press the OK button. Choose ”On-line” if the Model
49 is used together with a feeder Model 306/310 and/or a mailer/inserter Model 45 and/or
Booklet Feeder Model 46. Choose ”Stand Alone” to use the Model 49 as a stand alone
document feeder. If the Model 49 should be inactivated choose ”Off-line”. Confirm your
choice by pressing the OK button.
Select “Job Set” and press the OK button. From “Adjustment Menu” it is possible to scroll and
enter any of the adjustable parameters.
Select ”Length” and press the OK button. Enter the length of the inserts (in the feed direction)
using the arrow buttons. The range is 100 to 310 mm. Default value is 200 mm. Confirm by
pressing the OK button.
Select ”Sets per hour” and press the OK button. Enter the number of sets per hour using the
arrow buttons. The range is 1000 to 3600 sets per hour. Default value is 1800. The speed will
however be limited to match units attached. Confirm by pressing the OK button.
Select ”Sheets per set” and press the OK button. Enter number of sheets per set using the
arrow buttons. The range is 1 to 50 sheets per set. Default value is 1. Confirm by pressing the
OK button.
Select “Advanced Setup” and press the OK button.
Select ”Belt speed” and press the OK button. Enter a percentage using the arrow buttons.
The range is 60 to 100%. Default value is 80%. Confirm by pressing the OK button.
Select “Lug Speed” and press the OK button. Enter a percentage using the arrow buttons.
The range is 30 to 140%. Default value is 70%. Confirm by pressing the OK button.
Select “Eject Speed” and press the Ok button. Enter a percentage using the arrow buttons.
The range is 30 to 140%. Default value is 100%. Confirm by pressing the OK button.
Select “Trig Delay” and press the OK button. Enter the time (millisecond) using the arrow
buttons. The range is 30 to 1000 ms. Default value is 50 ms. Confirm by pressing the OK
button.
3.4 Programming the Model 49
