T10114 Jan 2001
Sheet Feeder Model 49 Operator Manual
4. Diagnosis
4.1 Diagnosis
5. Maintenance
5.1 Cleaning the Feed Belts
Clean the insert feed belts using a mild soap detergent every
10 000 feeds or earlier if needed.
Note: Before starting the diagnosis, all inserts must be removed.
Select ”DIAGNOSIS” from the ”Options Menu” and press the
OK button at the ”Diagnosis Menu” to start the self test.
The self test will check: memory, insert sensor (S1), outfeed
sensor (S2), set sensor (S3), lug belt senor (S4),voltage
supplied from the power pack and feed belt motor (M1),set
delivery motor (M2) and (OMR) if it is connected to the
system. During the test, the display will show which part that
currently is tested. After the test you can scroll with the arrow
buttons to check that all parts diagnosed, passed the test.
If any tested part did not pass the test.
If any of the sensors should fail the self test, check if sensors
are blocked with paper dust. If so, clean them and perform
the self test again. If cleaning does not correct the problem,
or if any other of the parts checked fails the test, have the
Model 46 checked by a qualified technician.
4-1
LANGUAGE
DIAGNOSIS
Run Diagnosis?
MEMORY:PASSED
S1:
Exemple: Display shows that
the Model 49 passed the
memory test and testing of
sensor S1 in progress.
