OPERATE COMMAND TABLE
Command
Code
Command Description
Command
Syntax
60
Password
See programming table for default values
60 [PASSWORD] #
61
Program Authorization Code (PAC)
See programming table for default values
61 [PROGRAM AUTH] #
00
End telephone communication
00 #
01
Arm / Disarm system
Data = 0 (Disarm), 1 (Arm), None (Toggle)
01 [KEY CODE] <DATA> #
02
Read back loop circuit status
Loop = 1 through 8
02 [KEY CODE] <LOOP> #
03
Read Back last alarm status
Date and time is included if RAM/RTC has been installed
03 [KEY CODE] #
04
Turn loop ON/OFF for alarm output
Loop = 1 through 8, Data = Zero (Off) / Non Zero (On)
04 [KEY CODE] [LOOP] [DATA] #
05
Monitor mode ON / OFF
Data = Zero (Off) / Non Zero (On)
05 [KEY CODE] <DATA> #
06
N/A
07
N/A
08
N/A
09
Relay and digital output control
R/D = 0 (Relay) / 1 (Digital), Data = Zero (Off) / Non Zero (On)
09 [KEY CODE] [R/D] [DATA] #
62
ADC OPTION: Read ADC input value directly
Input = 1 through 8
62 [INPUT] #
63
ADC OPTION: Read ADC integrated value
Input = 1 through 8
63 [INPUT] #
64
ADC OPTION: Read high (maximum) value
Input = 1 through 8
64 [INPUT] #
65
ADC OPTION: Read low (minimum) value
Input = 1 through 8
65 [INPUT] #
67
ADC OPTION: Read analog scaled value
Input = 1 through 8
67 [INPUT] #
#
=
ENTER, END OF COMMAND STRING
*
=
CLEAR, START COMMAND OVER AGAIN
[ ]
=
PROMPTS USER FOR MISSING PARAMETERS
< >
=
PROMPTS USER FOR OPTIONAL PARAMETERS
