SPEECH LIBRARY
If your application requires words that are not listed in this manual, additional words and custom words are available from
the factory. Please contact the factory for more information on supplemental words.
The following include a full list of all words that are currently supplied with the PET-820 and a Speech Message Buffer
Programming Tables have been provided to assist you in setting up the system messages.
When setting up a message buffer, the message should start with a 750 mS pause (WORD ADDRESS 001) however this
pause is not required. The message buffer must always end with a End of Message (WORD ADDRESS 000). Each message
buffer is only 16 words long but if longer messages are required, then you can string message buffers together by not using an
end of message command word until the last buffer.
WORD
SPEECH COMMAND WORD
ADDRESS
END OF MESSAGE
000
750 mS PAUSE
001
SPEAK TIME (HH:MM AM/PM)
002
SPEAK DATE (MM-DD-YY)
003
(1)
SPEAK BCD DATA, SUPPRESS LEADING ZERO (HTM)
004
(1)
SPEAK HEX DATA, NEXT BYTE = START POSITION
005
SPEAK ALARM STATUS LOOP NUMBER
006
SPEAK SYSTEM ADDRESS
007
(1)
SPEAK FROM INT RAM, 4 WORDS MAX (SP_BUFF)
008
GOOD MORNING/AFTERNOON/EVENING
009
N/A
010
SPEAK ALARM STATUS, ANALOG VOLTAGE
011
N/A
012
NULL WORD, USE TO CLEAR WORD OR FILL SPACE
013
SELECT SPEECH LIB, LOW WORD GROUP
014
SELECT SPEECH LIB, HIGH WORD GROUP
015
(1)
These speech command words are typically used by the program and serve no practical use for user programmable
speech.
LOW WORD GROUP
LOW WORD GROUP
LOW WORD GROUP
WORD
ADDRESS
WORD
ADDRESS
WORD
ADDRESS
ZERO
016
SIXTEEN
032
B
048
ONE
017
SEVENTEEN
033
C
049
TWO
018
EIGHTEEN
034
D
050
THREE
019
NINETEEN
035
E
051
FOUR
020
TWENTY
036
F
052
FIVE
021
THIRTY
037
G
053
SIX
022
FORTY
038
H
054
SEVEN
023
FIFTY
039
I
055
EIGHT
024
SIXTY
040
J
056
NINE
025
SEVENTY
041
K
057
TEN
026
EIGHTY
042
L
058
ELEVEN
027
NINETY
043
M
059
TWELVE
028
HUNDRED
044
N
060
THIRTEEN
029
THOUSAND
045
O
061
FOURTEEN
030
MILLION
046
P
062
FIFTEEN
031
A
047
Q
063
